Quality

At Apogee Semiconductor, quality is engineered into every stage of development, from architecture and design through manufacturing and long-term product support.

key pillars of Apogee’s quality approach

Design & Change Control

Structured design reviews, verification planning, and formal change control processes ensure product integrity from concept through production.

Manufacturing & Supplier Oversight

Apogee works with qualified foundry, assembly, and test partners and maintains oversight through documented processes, traceability, and supplier performance monitoring.

Reliability & Qualification

Products are evaluated through defined qualification flows and reliability assessment to support robust operation across expected environmental and electrical conditions.

Continuous Improvement

Quality metrics, corrective action processes, and engineering feedback loops enable continuous improvement in both design and manufacturing processes.

Quality / Quality

Product grades and quality flows

Apogee Semiconductor offers its products in four production grades: A-Grade, B-Grade, C-Grade, and E-Grade (Evaluation). Each grade follows a defined production, screening, and lot acceptance flow.

Production flows

A-Grade B-Grade C-Grade E-Grade
Packaging Plastic Plastic Plastic Plastic
Bond wires Au Au Au Au
Pure tin (Sn) used No No No No
Production burn-in Yes No No No
Operating temperature range -55 °C to 125 °C -55 °C to 125 °C -55 °C to 125 °C -55 °C to 125 °C (Note 1)
Tested temperatures -55 °C, 25 °C, 125 °C -55 °C, 25 °C, 125 °C 25 °C 25 °C
Radiation (TID) lot acceptance (RLAT) Yes Yes Yes Note 1
Outgassing tested per ASTM E595 Yes Yes Yes Note 1
Lot-level temperature cycle Yes Yes Yes Note 1
Lot-level HAST Yes Yes Yes Note 1
Life test per wafer lot (HTOL) Yes Yes Yes Note 1
Multiple wafer lots per reel possible No No No Yes

Table 1: Apogee Semiconductor production flows

Note 1: Evaluation Grade parts are intended for engineering evaluation only. These units are not suitable for qualification, production, radiation testing, or flight use and are not warranted as to performance over temperature, radiation, or operating life. Evaluation Grade devices are provided without any radiation hardness guarantees and may not have completed full device qualification.

Note 2: E-Grade devices with an X preceding the date code (YYWW) are not the final version of the product. X-marked products are sold only while a device is in pre-production status, as indicated by the datasheet, and X-marked status is shown in the ordering information table of the pre-production datasheet. For details about a specific product, contact support@apogeesemi.com.

Inline screening flow

Inline screening flow for A-, B-, C-, and E-Grade products
Figure 1: Inline screening flow Select to enlarge

Lot acceptance flow

Figure 2: Lot acceptance flow Select to enlarge

Need grade or screening details for a specific part? Contact our quality team.

Quality / Quality

MIL-PRF-38535 and EEE-INST-002 compliance

The matrices below show how the inline screening and quality conformance inspection (QCI) flows for Apogee Semiconductor Grade A TSSOP devices align with MIL-PRF-38535 and EEE-INST-002.

EEE-INST-002 is a specification developed by the National Aeronautics and Space Administration (NASA). Apogee Grade A TSSOP devices most closely align with Section M4 of EEE-INST-002, which covers plastic encapsulated microcircuits (PEMs).

MIL-PRF-38535 is a specification developed by the Defense Logistics Agency (DLA). Apogee Grade A TSSOP devices most closely align with its QML Class P guidelines. Inline screening guidelines are in Table IA of MIL-PRF-38535, and QCI guidelines are in Tables II through V and Table C-I.

Table key

A
Aligned
X
Not aligned
S
Similar (see comments)
NA
Not applicable; either not applicable for TSSOP plastic packages or not required for the indicated specification

Inline screening alignment matrix

Table 2: Inline screening alignment matrix
MIL-PRF-38535 # EEE-INST-002 # Description MIL Spec Standard EEE-INST-002 (M4 Level 1) Standard Apogee QMLP Alignment Apogee EEE-INST-002 Alignment Comments
1 Wafer lot acceptance QM plan (see H.3.2.1.4) or TM 5007 of MIL-STD-883 S NA Internal QM plan.
2 Nondestructive bond pull (NDBP) test NA NA
3 Internal visual inspection TM 2010, condition A S NA Sample size and magnification level varies by assembly site.
4 2 Temperature cycling TM 1010, condition B, -55 °C to 125 °C, 15 cycles minimum S S Equivalent condition is also used: TM 1010, condition C, -65 °C to 150 °C, 10 cycles minimum.
5 Constant acceleration NA NA
6 1 Visual inspection 100% Per paragraph 5.3.1 of PEM-INST-001 NA A Optional per MIL-PRF-38535. Units are sampled for visual inspection.
7 Particle Impact Noise Detection (PIND) test NA NA
8 1 Serialization In accordance with device specification (100%) Per paragraph 5.3.1 of PEM-INST-001 A A
9 5 Pre burn-in (interim) electrical parameters test In accordance with device specification Per device specification, at 25 °C and at min. and max. rated operational temperatures A S 25 °C only.
10 9 Burn-in test TM 1015, 240 hours at 125 °C, condition D MIL-STD-883, Method 1015, Cond. D, hours minimum A A
11 Post burn-in (interim) electrical parameters test In accordance with device specification NA NA
12 7 Reverse bias burn-in test (static burn-in) TM 1015, condition A or C; 144 hours at +125 °C or 72 hours at +150 °C minimum MIL-STD-883, Method 1015, condition A or B, hours minimum depending on the burn-in temperature NA X
13 7a Post burn-in (interim reverse bias) electrical parameters test In accordance with device specification NA NA
14 11 Percent defective allowable (PDA) calculation 5 percent PDA; 3 percent PDA for functional parameters at 25 °C A A
15 10 Final electrical tests In accordance with applicable device specification Per device specification (at 25 °C, maximum, and minimum rated operating temperatures) A A
16 Seal test NA NA
17 3 Radiographic (X-ray) and/or acoustic microscopy test X-ray: TM 2012 Per paragraph 5.3.2 of PEM-INST-001 A A
18 12 External visual inspection TM 2009 Per paragraph 5.3.1 and Section 8 of PEM-INST-001 S A Units are sampled for visual inspection.
4 C-SAM inspection Per paragraph 5.3.3 of PEM-INST-001 NA X
6 Engineering review (Steps 1 to 5) NA X
Destructive Physical Analysis (DPA) 5 samples per Section 5 of PEM-INST-001 NA X

Quality conformance inspection (QCI) alignment matrix

Table 3: QCI alignment matrix
MIL-PRF-38535 Group EEE-INST-002 # Description MIL Spec Standard EEE-INST-002 (M4 Level 1) Standard Apogee QMLP Alignment Apogee EEE-INST-002 Alignment Comments
Group A 1-11 Final test QA resample 116(0) or 100 percent / 0 sample X NA
Group B1 Resistance to solvents TM 2015 NA NA
Group B2a Bond strength TM 2011 X NA Controlled by assembly site SPCs.
Group B2b Die shear test or substrate attach strength or stud pull test including passive elements TM 2019 or TM 2027 X NA Controlled by assembly site SPCs.
Group B3 Solderability TM 2003, solder temperature +245 °C ±5 °C X NA Tested once during device qualification.
Group B4a Ball shear test for BGA package JESD22-B117 NA NA
Group B4b Solder column pull test for CGA package TM 2038 NA NA
Group C1a 6 Steady-state life test TM 1005, 45(0), 1000 hours at 125 °C MIL-STD-883, Method 1005, Cond. D, hours minimum A S 45 samples for 1000 hours at 125 °C.
Group C1b 6 End-point electrical parameters As specified in the applicable device procurement specification Measure at 25 °C, min. and max. rated temperatures A A
Group D1 Physical dimensions TM 2016 X NA Leads are preformed, which is considered an acceptable substitute per TM 2004 condition B2.
Group D2a Lead/terminal integrity test TM 2004 condition B2 (lead fatigue) or applicable for the package technology style X NA Leads are preformed, which is considered an acceptable substitute per TM 2004 condition B2.
Group D2b Seal test NA NA
Group D2c BGA/CGA ball/column shear/pull test NA NA
Group D3a Thermal shock NA NA
Group D3b 4 and 5 Preconditioning required JESD22-A113 JESD22-A113-B, para. 3.1.5, condition A (168 hours, +85 °C, 60% RH) A A Post-stress testing is done at 25 °C only.
Group D3b 3 Temperature cycling – C-SAM pre Section 5, paragraph 5.3.1 of PEM-INST-001 A A
Group D3b 6a Temperature cycling TM 1010, condition B (150 cycles min.) MIL-STD-883, Method 1010, Cond. B (-55 °C to +125 °C), cycles minimum A A
Group D3b 6a Temperature cycling – C-SAM post Section 5, paragraph 5.3.3 of PEM-INST-001 A A
Group D3c 5 Preconditioning required JESD22-A113 JESD22-A113-B, para. 3.1.5, condition A (168 hours, +85 °C, 60% RH) A A
Group D3c 7 Moisture resistance JESD22-A118 Unbiased HAST Condition B and/or JESD22-A110 Biased HAST Condition B A A
Group D3d Visual examination In accordance with visual criteria of TM 1004 or TM 1010 A NA Inspected per JESD22-B101D.
Group D3e Seal test NA NA
Group D3f 6a End-point electrical parameters As specified in applicable device specification Measure at 25 °C, min. and max. rated temperatures A A
Group D4 Mechanical shock and vibration NA NA
Group D5a Salt atmosphere TM 1009, test condition A minimum X NA
Group D5b Visual examination In accordance with visual criteria of TM 1009 X NA
Group D5c Seal test NA NA
Group D6 Internal gas NA NA
Group D7 Adhesion of lead finish Where applicable, TM 2025 X NA
Group D8 Lid torque Where applicable, TM 2024 NA NA
Group D9 Soldering heat, fine leak, gross leak, visual inspection, and end-point electrical testing NA NA
Group E1a Neutron irradiation test (initial qualification test or QCI/TCI test) TM 1017 at 25 °C X NA NDD testing is ongoing for existing and new products.
Group E1b Endpoint electrical parameters test As specified in the applicable device procurement specification X NA NDD testing is ongoing for existing and new products.
Group E2a 2 Total ionizing dose (TID) test (initial qualification test or QCI/TCI test) TM 1019 at 25 °C, maximum supply voltage A A
Group E2b 2 Endpoint electrical parameters test As specified in the applicable device procurement specification A A
Group E3a 2 Dose rate upset test (transient irradiation test) Digital: TM 1021; Linear: TM 1023 (temperature at 25 °C) X X
Group E3b 2 Endpoint electrical parameters test As specified in the applicable device procurement specification X X
Group E4 2 Radiation dose rate induced latch-up test TM 1020 X X
Group E5 2 Single event effects (SEE) test ASTM F1192 or JESD57 A A SEE testing is done for technology characterization and qualification and is not performed at the lot level. Go to apogeesemi.com for detailed SEE reports.
1 Visual inspection and serialization Section 5, paragraph 5.3.1 of PEM-INST-001 NA A 100% visual inspection and serialization is completed inline.

Need the full alignment document or details for a specific device? Request quality documentation.

Quality / Quality

Product change notification

After a product is released, Apogee continues to improve its products and processes, so we may need to modify or update a product or a manufacturing process. Apogee Semiconductor issues Product Change Notifications (PCNs) so customers are informed before changes that may affect form, fit, function, quality, or reliability.

Change notification process

Apogee’s PCN process follows JEDEC J-STD-046. Customers are notified of major changes that affect the form, fit, or function of a product, or that adversely affect its quality or reliability. Before implementing any notifiable change, Apogee provides:

  • A detailed description of the change
  • The reason for the change
  • A PCN tracking number
  • Identification of affected products
  • Apogee contact information
  • Anticipated positive or negative impact on fit, form, function, quality, and reliability
  • The qualification plan and results, or the qualification schedule if results are not yet available
  • Sample availability date
  • Projected production shipment date

Further details on the PCN process are available in Apogee’s General Quality Guidelines, which you can request from our quality team.

Receiving PCNs

PCNs are distributed by email to registered customers. To register, or to request the PCN history for a specific product, contact quality@apogeesemi.com.

Questions about a specific change? Contact our quality team.

Quality / Quality

Product obsolescence

Apogee’s product withdrawal and discontinuance process complies with JEDEC J-STD-048. We work to avoid discontinuing products for convenience, and our standard withdrawal schedule gives customers more lead time than the industry standard.

Withdrawal schedule

Our standard schedule allows 12 months to place last orders, plus an additional six months to take final delivery. In rare cases an accelerated schedule may be necessary; affected customers will then be told the last-time-buy and final delivery dates.

What obsolescence notifications include

  • A detailed description
  • A PCN tracking number
  • Apogee contact information
  • Last order date (no more than 12 months after notification)
  • Last delivery date (up to six months after the order period ends)
  • Identification of affected products
  • Identification of a replacement product, if applicable

Obsolescence notifications are distributed the same way as PCNs. To register, contact quality@apogeesemi.com.

Questions about a discontinued or end-of-life product? Contact our quality team.

Quality / Quality

Anti-counterfeit

Apogee Semiconductor is committed to preventing counterfeit components from entering the supply chain, in accordance with JEDEC JESD243A and SAE AS5553. To reduce the risk of counterfeit parts, we strongly encourage customers to buy Apogee products only from authorized sources: directly from Apogee or from an Apogee-authorized distributor.

Why authorized sources matter

Counterfeit parts often carry markings and labels that closely resemble genuine Apogee products. Because they are not manufactured, packaged, labeled, stored, or shipped to Apogee’s standards, they pose serious performance, safety, and reliability risks.

Products bought outside Apogee’s authorized sources, including from brokers, independent distributors, or online marketplaces, may be counterfeit or unreliable. Apogee does not provide warranty coverage or customer support for products purchased outside its authorized sources, and cannot guarantee their authenticity.

Authorized channels

The only authorized sources for Apogee Semiconductor products are:

  • Direct purchase from Apogee Semiconductor
  • Authorized distributors listed on our distributors page

How we protect the supply chain

  • Authorized distributor program: distribution agreements define the scope of each distributor’s authorization.
  • Certificate of conformance: included with every shipment.
  • Product traceability: device marking and shipping records support full traceability of all Apogee Semiconductor products.
  • Product validation: customers who need to verify the authenticity of an Apogee component can submit a validation request to quality@apogeesemi.com.

Reporting suspect counterfeit parts

If you believe you have received a suspect counterfeit Apogee Semiconductor component, contact us immediately at quality@apogeesemi.com.

Need to verify a part or report a concern? Contact our quality team.

Quality / Certifications and standards

ISO 9001 certificate

Apogee Semiconductor’s quality management system is certified to ISO 9001.

ISO 9001 certified

View the ISO 9001 certificate (PDF)

Quality documentation

Our Quality Document Package bundles certificates and quality policy documents for customer qualification and supplier audits.

Download the Quality Document Package (.zip)

Need a document that isn’t listed here? Request quality documentation.

Quality / Reliability

Product shelf life

How long a semiconductor product can be stored after delivery depends on the materials used in the device, manufacturing conditions, its moisture sensitivity level (MSL), whether it ships in a moisture barrier bag (MBB), the amount of desiccant included, and how the customer stores it. Apogee controls its internal manufacturing and storage processes so that products reach customers with appropriate shelf life performance.

Apogee product storage

The minimum useful life of an Apogee product is measured from the date of delivery to the customer, not from the manufacturing date. Apogee’s manufacturing date code has no effect on a product’s usage, quality, or reliability.

Both the minimum useful life of a product and the Apogee warranty period begin when the product is delivered to the customer. For details, see our Terms of Sale.

Customer storage and handling

Customer shelf life is the length of time a customer can properly store a product after delivery, and it depends heavily on storage and handling. The MSL information printed on Apogee bags and boxes states how long parts can be exposed to the environment.

Moisture-sensitive products ship in dedicated MBBs with a defined quantity of desiccant and a humidity indicator card (HIC). If the HIC shows pink at the 10% level or higher, the parts in that bag must be baked before use.

Apogee builds, manages, and holds inventory to support continuity of supply. This makes products more immediately available and reduces the impact of production constraints and end-of-life transitions on mature products.

Questions about storage or handling for a specific product? Contact our quality team.

Quality / Suppliers

Personnel awareness

All external providers conducting business with Apogee Semiconductor are required to comply with Apogee’s supplier requirements. By accepting a purchase order from Apogee Semiconductor, suppliers acknowledge and agree to these terms.

What supplier personnel must be aware of

Suppliers shall ensure that personnel involved in work for Apogee Semiconductor are aware of:

  • Their contribution to product and service conformity: the work performed by supplier personnel directly impacts the quality and reliability of products delivered to Apogee’s aerospace and defense customers.
  • Their contribution to product safety: errors or nonconformances at the supplier level can result in safety-critical failures in end-use applications.
  • The importance of ethical behavior: suppliers are expected to conduct business with integrity, report concerns transparently, and avoid practices such as counterfeit part substitution or falsification of records.

Supplier questions? Contact Apogee Semiconductor.

Quality / Environmental information

RoHS declaration

Apogee Semiconductor provides environmental compliance information for its products to support customers’ material declarations and regulatory reporting.

RoHS compliance

TO FILL IN: Apogee’s RoHS compliance statement, including the directive version it is assessed against and any exemptions that apply.

Download the RoHS declaration (PDF)

Need a material declaration or compliance document for a specific product? Contact our quality team.

Quality / Environmental information

REACH declaration

Apogee Semiconductor provides environmental compliance information for its products to support customers’ material declarations and regulatory reporting.

REACH compliance

TO FILL IN: Apogee’s REACH statement, including whether products contain Substances of Very High Concern (SVHCs) above the reporting threshold and the candidate list date the declaration covers.

Download the REACH declaration (PDF)

Need a material declaration or compliance document for a specific product? Contact our quality team.

Quality / Environmental information

Conflict minerals policy

Apogee Semiconductor provides environmental compliance information for its products to support customers’ material declarations and regulatory reporting.

Conflict minerals

TO FILL IN: Apogee’s conflict minerals policy statement and whether a Conflict Minerals Reporting Template (CMRT) is available on request.

Download the conflict minerals policy (PDF)

Need a material declaration or compliance document for a specific product? Contact our quality team.

Quality / Reliability

Moisture sensitivity level (MSL)

Apogee characterizes its products for moisture sensitivity in accordance with JEDEC J-STD-020, the industry standard for moisture/reflow sensitivity classification of nonhermetic surface mount devices.

How products are classified

Classification is determined empirically: each product family undergoes controlled moisture soak and reflow stress testing to establish its MSL rating.

MSL ratings

MSL level Floor life (at ≤30 °C / 60% RH) Notes
MSL 1 Unlimited No dry pack required
MSL 2 1 year –
MSL 2a 4 weeks –
MSL 3 168 hours –
MSL 4 72 hours –
MSL 5 48 hours –
MSL 5a 24 hours –
MSL 6 Time on label (TOL) Mandatory dry pack

MSL ratings and floor life

Note: Most Apogee Semiconductor products are currently characterized at MSL 1. They have unlimited floor life under standard ambient conditions and do not require dry pack or MBB packaging.

Need the MSL rating for a specific product? Contact our quality team.

Quality / Suppliers

Supplier requirements

All external providers conducting business with Apogee Semiconductor are required to comply with Apogee’s supplier requirements. By accepting a purchase order from Apogee Semiconductor, suppliers acknowledge and agree to these terms.

Quality and compliance requirements

Suppliers shall:

  • Maintain a quality management system appropriate to the products and services provided. Where required by Apogee or its customers, suppliers may be required to use customer-designated or approved external providers or process sources.
  • Notify Apogee Semiconductor promptly of any nonconforming processes, products, or services and obtain written approval prior to disposition.
  • Take all necessary measures to prevent the use, procurement, or delivery of counterfeit parts.
  • Notify Apogee Semiconductor of any changes to processes, products, or services, including changes to their own supply chain or location of manufacture, and obtain Apogee’s approval prior to implementation.
  • Flow down all applicable Apogee and customer requirements to their own sub-tier suppliers.
  • Provide test specimens upon request for design approval, inspection, verification, investigation, or auditing purposes.
  • Retain all relevant documented information, including records, for a minimum of 10 years. Upon expiration of the retention period, contact Apogee Semiconductor for disposition instructions.

Supplier questions? Contact Apogee Semiconductor.

Quality / Suppliers

Right of access

All external providers conducting business with Apogee Semiconductor are required to comply with Apogee’s supplier requirements. By accepting a purchase order from Apogee Semiconductor, suppliers acknowledge and agree to these terms.

Access requirements

Apogee Semiconductor, its customers, and applicable regulatory authorities reserve the right of access to all relevant facilities, processes, and documented information at any level of the supply chain.

Supplier questions? Contact Apogee Semiconductor.

Quality / Suppliers

Defense Priorities and Allocations System (DPAS)

All external providers conducting business with Apogee Semiconductor are required to comply with Apogee’s supplier requirements. By accepting a purchase order from Apogee Semiconductor, suppliers acknowledge and agree to these terms.

DPAS-rated orders

Apogee Semiconductor’s products may be used in programs subject to the Defense Priorities and Allocations System (DPAS). Purchase orders issued by Apogee Semiconductor may carry a DPAS priority rating.

Suppliers are required to accept and give preferential treatment to DPAS-rated orders and to flow down the applicable priority rating to their own sub-tier suppliers in accordance with DPAS regulations.

Supplier questions? Contact Apogee Semiconductor.

Terms of Sale v1-15/10/2026
